Switcher Kramer DIP-30 HDMI

Liên Hệ

The DIP−30 is a 4K UHD automatic switcher for HDMI, VGA, Ethernet, data and unbalanced audio signals. The unit supports resolutions up to 4K@60Hz (4:2:0) UHD and various modes of input selection and transmits the signal via HDMI cable to a compatible receiver (for example the VS−62H or when connecting directly to a display/projector). The DIP−30 is a Step−in commander when connected to a matrix switcher that supports Step−in over HDMI such as the VS−62H.

Max. Resolution — 4K@60Hz (4:2:0) UHD and WUXGA.
Max. Data Rate — 10.2Gbps (3.4Gbps per graphic channel).
HDTV Compatible.
HDCP Compliant — With sources that support HDCP repeater mode.
HDMI Support — Deep Color, x.v.Color™ and 3D.
Automatic Live Input Detection — Based on video clock presence.
Automatic Input Selection — Based on priority selection or last connected input.
Manual Input Selection.
Step–in Support.
Automatic Analog Audio Detection & Embedding.

Bảo Hành:

12 Tháng

Tình Trạng

: Đang Có Hàng

Nhà Sản Xuất

: Switchers and Matrices

INPUTS

· 2 HDMI on HDMI connectors, 1 VGA on a 15–pin HD (F) connector, 1 unbalanced stereo audio 1V RMS (nominal) on a 3.5mm mini jack

OUTPUTS

· 1 HDMI connector, 1 unbalanced stereo audio 1V RMS (nominal) on a 3.5mm mini jack

PORTS

· 1 Ethernet on an RJ–45 connector, 1 RS–232 3–pin terminal block control port, 1 RS–232 3–pin terminal block data port (internal use), 1 USB on mini USB connector

CONTROLS

· Remote switches for input switching, step–in, volume control, and device reset switch

STANDARDS

· HDMI with Deep Color, x.v.Color™ and 3D, HDCP—works with sources that support HDCP repeater mode

MAXIMUM ANALOG AUDIO LEVELS

· 3.1Vpp

SNR

· –70dBu

THD

· 0.013%

SUPPORTED WEB BROWSERS

· Windows 7 and higher: Internet Explorer (32/64 bit) version 11, Firefox version 30, Chrome version 35

· MAC:Chrome version 35, Firefox version 27, Safari version 7; Android OS: Chrome version 35; iOS:Chrome version 35, Safari version 7

POWER CONSUMPTION

· 12V DC, 560mA

OPERATING TEMPERATURE

· 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE

· –40° to +70°C (–40° to 158°F)

HUMIDITY

· 10% to 90%, RHL non–condensing

COOLING

· Convection

ENCLOSURE TYPE

· Aluminium

ENVIRONMENTAL REGULATORY COMPLIANCE

· Complies with appropriate requirements of RoHs and WEEE

INCLUDED ACCESSORIES

· Power supply, ADC–DPM/HF DisplayPort (M) to HDMI (F) adapter cable, (for connecting a DisplayPort source to the HDMI input), DIP–30BP black panel

OPTIONS

· RK–T2B 19" rack adapter , DIP–30BP black front panel for DIP–30

WARRANTY

· 7 years parts and labor

PRODUCT DIMENSION

· 18.75cm x 11.50cm x 2.54cm (7.38" x 4.53" x 1.00" ) W, D, H

PRODUCT WEIGHT

· 0.4kg (0.9lbs) approx

SHIPPING DIMENSION

· 34.50cm x 16.50cm x 5.20cm (13.58" x 6.50" x 2.05" ) W, D, H

SHIPPING WEIGHT

· 1.0kg (2.3lbs) approx
