Model
|
HD920-U20-K5
|
|
SenSor
|
Sensor
|
1/2.8" Progressive CMOS
|
|
Effective Pixel
|
2.1 Megapixel
|
|
Min.Illumination
|
0.5 Lux at F1.6
|
|
White Balance
|
Auto/Manual
|
|
Gain Control
|
Auto
|
|
Back Light Compensation
|
On/Off
|
|
Electronic Shutter
|
1/60 - 1/10,000S
|
|
SN Ratio
|
>50db
|
|
Lens
|
Focus
|
f=4.7-94mm F1.6-F3.5
|
|
Iris
|
Auto/Manual
|
|
Zoom
|
20 Optical X 12 Digital
|
|
HOV
|
3.2°（T）~58.7°（W）
|
|
Video Output Interface
|
USB2.0
|
|
Video Output Format
|
USB2.0:1080P30(MJPG),720P30（MJPG）,640×480
|
|
Control terminal
|
RS-232C, RS-485,usb
|
|
Control Protocol
|
VISCA,PELCO-D
|
|
baud rate
|
9600/38400bps
|
|
patrol line
|
4 cruise sequence
|
|
preset position
|
64 preset positions
|
|
Speed Match
|
Pan/Tilt movement speed depends on camera module zoom in/out
|
|
OSD Menu
|
Access to OSD Menu and adjust camera module parameters
|
|
Image auto flp
|
Support
|
|
Pan movement speed
|
1-60°/S
|
|
Tilt movement speed
|
1-60°/S
|
|
Pan movement range
|
355°
|
|
Tilt movement range
|
90°（Up）,45°（Down）
|
|
Pan scanning automatically
|
Support Pan scanning automatically
|
|
Boundary scanning
|
0-355°(programmable)
|
|
Remote controller
|
IR Wireless Remote controller P/T/Z
|
|
Power supply
|
DC12V,2A
|
|
Work Temperature
|
0-50℃
|
|
Humidity
|
0-95%RH
|
|
LxWxH
|
145mm×148mm×160mm
|
|
Weight
|
915g
|
